So how am I judging this??

First, all of these system can do the job. We are only considering their ease of use, cost, ROI and interoperability with other systems. How they handle imported data and how they communicate with manufacturing and other groups that depend on that information.

We are only considering the basic product. Only the solid modeling product with no modules. Not that adding modules is a bad thing, due to the very expensive initial costs of the high end systems, having the option to add only the capabilities you need keeps the price down. But it is nice to have all of the capabilities without jumping through a bunch of hoops to define your needs. It is nice to have surfacing available, that is a big reason to buy the mid-range products.

This is 3D CAD only, not CAE. No consideration is given to analysis or simulation capabilities.

Before we start there are other factors that make up a 3D CAD system. The follow topics are what can limit a 3D CAD package by adding costly complexities to the operation of the basic modeling. It is tailored more for upper and engineering management than the user. You can skip this if it is not of interest to you and go directly to the comparison below.

Telecom Giant Ericsson Halts Its PLM Project with Dassault’s 3DEXPERIENCE

PLM & PDM Defined

The top worst 3 programs are the PLM (Product Lifecycle Management) based programs. PLM and its supporting functionality such as MBD (Model-Based Definition) is basically an unworkable solution. I seem to be the only one beating this drum. I am a drafter and for years my job has been in making sure that manufacturing got precise and concise information in the form of the standard drawing. With 3D CAD the "drawing" was even made easier and more precise with ability to create the views directly from the solid Model. Since we don't actually do any "drawing", I have coined these not drawings but the AID (Associated Information Document) which gives a more accurate description of the process. There are many in the PLM industry that hate the word "Drawing".

The only purpose of engineering is to make available concise, complete and unambiguous documentation to manufacturing.

The Death of the Drawing

The Data Management Mess


Topic: E(E): One Revision to Rule Them All

You can see from the above article that there is a huge confusion in the PLM/PDM community. I was made aware of this from the complaints I was getting from my Boeing suppliers. They just ended up working around the PLM and MBD requirements. Boeing has even developed a Producibility Group!! I have watched Ed (the author of the above article) complain and complain about PLM. He is very smart yet he never comes up with any solutions. It is very easy to see why, there are so many problems with this system there is no place to start to fix it. The current PLM experts do not have the understanding of what engineering has to deliver to Manufacturing. None have ever even created a part/assembly and released it to manufacturing.

Engineering Documentation A Primer for the PLM Guru!

The Secret of Part Numbers

Here is a comment from the PLM PDM CAD Network on Linkedin.

Kais Al-Timimi
Managing Director at Datamation Limited

"Hi Joe I think everyone in this discussion agrees with your statement that “PLM in its current form will crumble”. Indeed we have been seeing it crumbling already, which is why we had the call for disruption. So, yes, I would like to see PLM to succeed, but not in its current form – this will never happen. The vision for next generation PLM that we should think of it as a “horizontal”, to manage all product information and not just the design. As such it will address all that is wrong with PLM now

I don’t think a PhD is needed to understand this. Simply to see it from the perspective of the total business, and not just from the design perspective. Furthermore, I don’t think any of the contributors to this discussion disputes the fact that the drawing has been, and continues to be, a convenient way of communicating design intent. But as several contributors have said, what it communicates represents only a fraction of the overall product data. As I said before, and Paul recently, we should see the drawing as a representation, or a snapshot of the design part of product data. As such it represents only one way of communicating design intent."

So unless you are interested in looking to your 3D CAD system to run your company on an unworkable non-standard engineering system take a look at these products. You will be wasting your time and money by redefining a proven and workable standard engineering system. There are better ways to maintain your engineering documentation than to hand it over to the 3D CAD system, thereby turning your engineers, designers and drafter into data managers.

Standard Cloud Based Engineering Document Control

Standard Cloud Based Engineering Document Control Part II

The Embedded Title Block! A PLM Solution!

Compare and Validation Programs?
Band-Aids for Self Inflicted Wounds!

So today we don't have to have the high end PLM system. We just need systems that can create and read a standard deliverable. We should have an open sourced standard document control system.

Universal 3D CAD Compatibility is NOT Here!

The Dreaded Pro/e Paradigm

It is quite amazing that all of the programs, except for three or four, are basically Pro/e clones and are directly based on the Pro/e paradigm. The history based only programs have been a known horror show for quick and easy changes. We all know that the only constant in engineering is change. Sometimes the parts are so poorly done that they have to be recreated, opening the door to huge oversights and errors. Most of the Pro/e clones now offer direct edit solutions which I will go into in each product description.

The Pro/E Paradigm – 25 Years of Incompatibility

3D CAD Productivity is an Oxymoron!!

Five Functions that Increase 3D CAD Productivity!!

The Ultimate 3D CAD System

Direct Edit Functionality

I have been beating the Direct Edit drum for almost 20 years. My problem is that I started in 3D CAD with 3D wireframe, moving to surfaces then to Boolean Solids (what we called direct editing in the beginning.) I started with CADKEY and was introduced to Trispectives in 1995. IronCAD was the first history based system to integrate direct editing in the design process. Trispectives, a graphic design program was bought by an OEM for CoCreate and they implemented the direct edit functionality with other engineering requirements. So I have had this functionality available to me throughout my career. With Pro/e, I saw an incredible amount of complexity necessary to design your parts with the upfront constraint and sketching requirements. Even though I was a Pro/e Dealer and had the package available (Still sitting in the Box) I could not justify its use or even recommend it to any of my customers.

The engineering world has finally woken up and are now providing direct edit functionality. Here are some of my articles promoting direct editing and its advantages.

Note: I have found that the Pro/e clones strict history based only system cannot incorporate direct edit functionality into the design process.

Next Generation 3D CAD Technology Applied!

Next Generation 3D CAD! The WIN-WIN Solution!


Are Solidworks Users NOT Stupid?

Welcome aboard Solidworks: Updated!

Welcome aboard Solidworks Rewrite!

The Single Model Design Environment

The most limiting function of the Pro/e paradigm is the separate part, assembly and drawing files. This feature alone had caused havoc in the industry leading to some very strange PLM and MBD solutions. Each of these high end PLM based programs have their unique PLM and PDM which is fine as long as you stay inside the program. But when they try to use the native files in the form of PMI their PLM system completely falls apart for those outside this system that need this information, such as purchasing, marketing, tech pubs, manufacturing, etc.

PMI (Produce Manufacturing infomation) vs AID (Associated Information Document)

Now many of you are experts in these system and have no real knowledge of any other system. The high end systems are very difficult to get experience since they are only being used by companies that can afford the enormous overhead costs required by these products. The companies demand that the designer be experienced in their system, there by making the pool for prospective engineering personnel limited in size. The goal of the industry should be creating a open system equal to what we had with board drawings, where industry experience is considered first.

Single Modeling Environment or UDE (Unified Design Environment)

Stuck with a 3D CAD System?

Most are stuck with their 3D CAD system. With many of the 3D CAD systems, now over 30 years old, we have legacy data and experience that have locked us into one system. We have faithfully stayed current with our maintenances at a couple thousand $$ or more per year per seat. Today they are threatening to move us to the "Cloud" assuring that we will be even more dependent on the 3D CAD vendor. We will now rent our software, but then we are paying an annual maintenance anyway!! When does it stop?

Are You Stuck in a 3D CAD Wagon World?

The Cost of Change

What would make you change your system? If you have a high end system it would be almost catastrophic. The cost of the system, training, data incompatibility, etc. So you are pretty much stuck with your system.

A New Level of Compatibility

The engineering world has been thrown into chaos with the myriad of 3D CAD systems that are available today. The lack of interoperability has increased the cost of engineering. The only thing that was added by 3D CAD was the solid model. Today we can take the solid model from any 3D CAD system and work with it in any other.

Universal 3D CAD Compatibility is NOT Here!

But we still need to set up a standard deliverable open format that frees us from being stuck in a single 3D CAD system. Now, we understand, if parametrics or programmed design is utilized that is very system sensitive, but it is rarely used. It was a good idea on paper.

We are at the mercy of the 3D CAD systems. They are in control of many companies engineering. We are locked into their program. Many are costing us a fortune to operate. We are being manipulated by those with a vested interest to keep us from moving to a open and cost effective standard 3D CAD solution. Hopefully there will be an outside organization, the colleges maybe, or industry associations that can take a look at standardizing the industry. Until then we will be stuck with this dated 3D CAD paradigm.


As a standard is established the need for so many different CAD systems will soon disappear. The cost will come down and we will end up with one common standard hybrid system on the order of Microsoft Office.  The standard CAD system will be available at a reasonable price to anyone interested. Document control will be an open system outside the CAD system. Released engineering will be in the form of a Standard deliverable that will be available to engineering and other pertinent departments.

The complexity of the past will yield to the simplicity of the future.

The 3D CAD Systems!

The next three programs should not even be considered unless you are a company with multi-year projects, with many concurrent users and outside suppliers and can afford the huge overhead costs required to implement and maintain the system or if you have an "in concrete" long term contract with a company that uses them. The basic cost of the system is miniscule compared the required IT supporting staff to maintain them. They are designed in such a way as to create a heavy dependence on the system demanding more and more support from the CAD vendor.

#1 Worst CAD system.

Dassault Catia 5

There is only one reason why this product is so popular?

The Boeing Airplane Company

Why did Boeing settle on Catia?? It was the only 3D CAD system that ran on an IBM workstation at the time. They had experimented with Computervision which ran on a somewhat undependable mainframe computer that required a refrigerated room. Each station cost around $250,000 with a minimum order of 3 seats, yes $750,000. They tried a couple of other systems that did not need this computer power, but had their own unique hardware. In those days no manager got fired for buying IBM. This was a very logical decision.

I have a bit of history with Catia. In 1986 I took a contract with Boeing Commercial in Everett and was assigned to 747 Flight Deck. I took the job to get back home. It was a board job even though I had 4 years of 3D CAD design experience on CV. Boeing did have a few seats of CV CADDS 3. The group had 5 seats of Catia 3. This was a 3D wireframe system with basic surfacing. The operators were prima donna drafters.

I was informed there was a PC based 3D CAD system on a couple of Compaq’s. It was 3D CADKEY, since I already had 3D wireframe experience on CV and CADKEY was very similar I was up and running in 2 weeks of lunch hours. I soon proved that it was a serious 3D CAD system by doing a somewhat large project, the First Observers Workstation. Soon we had 45 seats of CADKEY and eliminated one seat of Catia. Boeing commercial eventually ended up with 1200 seats of CADKEY.

Why isn’t CADKEY Boeing’s Major 3D CAD system?

The 1980's - 3D CAD - The Beginning

CADKEY or Catia? Boeing’s Billion-Dollar 3D CAD Mistake!

BCS (Boeing Computer Service). These folks were like the Gestapo. They could not control the new PC’s (Personal Computers) that were showing up everywhere. They actually had a vendetta against CADKEY. The grass root movement failed against this powerful organization.

Back to Catia 5. Yes, Catia 5, Catia 6 has been out for over 6 years and Boeing, Airbus and many other companies are not foolish enough to move to it. The reason?? Many of you may not know about the Catia 4 to 5 fiasco. Catia 5 can not directly read or even utilize Catia 4 files. Every plane prior to the 787 was being completely or partially designed in Catia 4. This was, and still is, a complete horror show for Boeing and AirBus. Not only was Catia 5 not compatible with Catia 4 it was basically not compatible with the rest of the industry. Catia 4 was a direct editing Boolean program but Catia 5 was and still is history only. Luckily for Boeing, many 3D CAD systems could read Catia native files. But if you received a Boeing file and you needed to modify it, Boeing could not incorporate the changes without modifying the original part or recreating the part altogether.

Beware Boeing! Dassault is now going to
 solve all your problems with "3DEXPERIENCE"!

Catia 4.5 - The Catia Incompatibility Solution

These comparisons show the problems Boeing faces with Catia 5. These are not to promote the products but show the huge document control problem this convoluted paradigm causes

IronCAD vs Catia Lesson 3 Assembly

Catia 5 was basically a Pro/e Clone. Pro/e hit the market so hard that all future 3D CAD systems had to have history based parametric solid modeling. But instead of just buying Pro/e, I am sure, Boeing working with Dassault came up with Catia 5 (with the help of Solidworks??). In an industry where change is the only constant, having a history based only system puts them in a place where they were at the mercy of the biggest CAD limitation: The Pro/e history only based paradigm. Add to that the high turnover of engineering personnel. Many of you have suffered with changing a complex history/feature based part. This paradigm depends heavily on the experience of the user. If you are inexperienced or not too bright you can create havoc in the building of even a not so complex part. I can only imagine the chaos in Boeing's and AirBus's engineering departments.

I was told by a friend at Boeing that they had this very bright engineer that was an expert on Catia 5 and was later trained on Catia 4. He said that Catia 4 was in many ways a much better system for aircraft design. The Pro/e history only paradigm is just too complex of a process to use for design in an industry where the only constant is change and with such a high turn over of designers.

I have worked with Boeing and Catia for over 30 years. Dassault is responsible for keeping Boeing one of the most ignorant and isolated manufacturing companies. Their lack of interoperability is beyond belief.

Conclusion: Stay away from Catia, the push from Dassault with this product today is not 3D CAD, but a poorly designed PLM system to run your engineering documentation and company. With prices starting at around $9,000.00 for the basic system and a variety of optional modules that can drive the price sky high without much ROI.

If you are stuck with Catia 5 there is a "huge" easy solution. You don’t even have to worry about legacy data. Products like IronCAD and ZW3D can not only read Catia 4, 5 and 6 native files, but can write Catia 4 and 5 native files. It is by far the easiest replaceable CAD system today, which is a bit weird since it is the least interoperable system.

It is a bit humorous that Dassault calls their products the "3DEXPERIENCE". The 3D experience has been here since 1982, at least for me!


Pro/e history/feature based only design.
Marginal direct edit available
Not a single model environment
High initial and maintenance costs.
Complicated operations.

#2 Worst 3D CAD system

PTC Creo (Pro/e) - Tech-Net sold this product

TECH-NET does not recommend purchasing any products from PTC. They are moving to a subscription only. We suggest you consider staying with a perpetual version or move to another package that offers a perpetual system. The problem is not just the subscription fee, but they now can hold your Intellectual Property hostage. No company can ignore this situation.

Creo seems to be a fragmented product.

PTC is responsible for putting 3D CAD on a path of standardizing of the most complex convoluted process for solid modeling ever devised. We are starting to finally overcome this tragedy that has cost and still costing the industry billions of dollars in incompatibility. Today all of the major 3D CAD programs are based on this dated paradigm putting the industry in an incompatibility head lock. None of the 3D CAD package based on this paradigm are compatible. Today, it is now more important for an engineer to have 3D CAD specific experience than industry related experience.

Next Generation 3D CAD Technology Applied

25 Years of 3D CAD Incompatibility - The New Generation of 3D CAD!!

I really don’t have to get into the operation of Pro/e and its limitations. Many of you experience it every day. In the beginning this was the only 3D CAD system that was designed for solid modeling from the ground up and could be deliver as single standalone seat. There was nothing to compare it. It was priced less than that the 3D wireframe/surfacing packages like CV and Catia and offered much more productivity by delivering the solid model even though its complex operation and had a very long, steep learning curve. The parametric functionality promised much more than it delivered. It could handle large assemblies and provide a technology hungry industry a viable solid modeling solution.

Companies would bring on the program and get everyone trained, sometimes taking 3 months to get familiar and up to a year to get proficient. Soon the companies that came on board later started to recruit the experienced Pro/e users with attractive rates. Soon many companies realized that they were becoming nothing more than Pro/e training centers. This, of course, led to experience in the 3D CAD system an employment requirement priority.

But back to 3D CAD. Pro/e has moved to Creo. There are two basic programs, Creo Parametric (Pro/e) and Creo Direct (CoCreate). Both are standalone systems. Creo Direct is an added cost to Creo Parametric. The base package is around $7000.00 if I remember right. I don't know the price of Creo Direct, but I am sure the cost of both packages is much more than NX which includes both functionalities. But the other optional modules can, like Catia, drive the price sky high. It is also mainly focused on providing a PLM solutions. These products are touted for large multiyear projects, with many concurrent users.

Conclusion: This is another product I would not recommend. It really does not offer the ease of use that are delivered with any of the systems below. And I feel they have not fully integrated the direct editing, mostly creating a fragmented CAD solution.


Pro/e history/feature based only design.
Direct Edit offered as an added option.

Not a single model environment
High initial and maintenance costs.
Complicated operations.

#3 Worst Not so bad CAD system

Siemens NX

NX seems to focus on MCAD more than both Catia and Creo. NX has robust somewhat faux integrated direct editing as part of their Pro/e paradigm program. They call this direct edit functionality ST Synchronous Technology. If it is like Solid Edge it is marginally usable and can cause some strange problems when integrated with history based design.

Ironcad vs Siemens ST

IronCAD vs NX Lesson 1 Assembly

ZW3D vs NX Lesson 1 Assembly

It, like the other PLM products, are delivering a non-standard or unique 3D CAD specific solution for handling the engineering data throughout the company. I am completely against these non-standard PLM solutions. We need a standard open system that these CAD companies MUST comply. This separate unique data management solutions are stifling the industry.

Conclusion: NX offers an attractive design solution. The price is probably out of the range of most companies/individuals and really doesn't offer any more productivity then many of the less expensive solutions below. Also PLM is an integrated part of the design program. So, I would save my money and pass on this one.

Not a single model environment
A faux integrated direct edit solution
High initial and maintenance costs.
Complicated operations.

#4 Worst Not so bad CAD system - Tech-Net sold this product

Siemens Solid Edge

We were a reseller for Solid Edge years ago when they were introducing Synchronous Technology, Siemens direct editing solution. It is very convoluted when working with history. It actually seems to cause more problems!

Ironcad vs Siemens ST

It has a very unintuitive user interface.

Conclusion: I would stay away from it.


A faux integrated direct edit solution
Not a single model environment
Complicated operations.

#5 Worst Not so bad CAD system - Tech-Net sold this product

Dassault Solidworks

Solidworks is basically a Pro/e clone with a bit more flexibility. You may ask “Why is this somewhat limited dated program so popular?” It was put on the market in 1995 and was a very limited design package. But it did one thing. It used what I call “Autocad’s Perpetual Evaluation Marketing” scheme. Which means there was no copy protection put on for 10 years, it was added with the release of SW 2007. Before that the product was enthusiastically passed around and many have a copy of SW 2006 laying around, maybe, still being used. But no company will have pirated software. With the recommendation of individuals, who don’t have a problem with non-licensed software, they started buying SW. The users were available and up to speed. As I have told so many other CAD companies, "You can only sell CAD on referrals".

There is really no reason to describe this product it really is just a Pro/e clone. But it is not just the price that makes it better than Pro/e. It has limited integrated direct edit functionality. Most of the users do not incorporate this into their design process because it adds a step for each direct edit function which makes it ineffective within the design process. It is priced much less than the above and offers equal if not superior performance.

Conclusion: Even though it is bit better that the above products, except for NX, it is still limited by the dated Pro/e paradigm of separate part, assembly and drawing files. This functionality is touted by its new supposedly companion product, SW Mechanical Conceptual (see below) as being a limiting function. They have introduced the Single Model Environment. They are right, this is the most productive function in CAD today. This is why I cannot recommend SW. It just does not offer the interoperability that is available in other products.

Welcome aboard Solidworks: Updated!


Not a single model environment
Direct edit functions are steps in the history
Complicated Operations

#6 Worst Sort of good CAD system - Tech-Net sold this product

TECH-NET does not recommend purchasing any products from Autodesk. They are moving to a subscription only. We suggest you consider staying with a perpetual version or move to another package that offers a perpetual system. The problem is not just the subscription fee, but they now can hold your Intellectual Property hostage. No company can ignore this situation.

You are Not Stuck with Autodesk

Autodesk Inventor

I was introduced to Inventor when I took a job with a company that was going to provide the Autodesk Manufacturing solution. I started the training tutorials and I was up and running in a week. I found the tutorials easy and informative. The tutorials started you working in top down or in context design which I was very familiar. This is where you would work in the assembly mode creating your separate parts. I have always worked in this mode, which is why the following products are superior to this and previous products.

It was my first experience designing in the assembly mode, even though, I had limited experience with Pro/e and SW designing parts, it was just to much work to follow up with assemblies and drawings. I was also introduced to Fusion which is the direct editing module. At that time it was a separate module and was fun to work with.

I did a design modifying the non-native part and even doing the drawing. I would change the part in the Fusion module and it would change in the drawing. They have now integrated the direct editing function in Inventor making it even more attractive. But each direct edit function is still part of the history. This is a problem since at this time you cannot incorporate the prior history when you do a direct edit function. Until they make the direct edit functionality more of the design process, I feel the basic Pro/e paradigm programs are not taking advantage of the two paradigms. It seems that they are incorporating direct editing to modify non-native parts, not to incorporate into their design process. Sadly they are not providing the industry with a new 3D CAD solution with smooth integration of history/feature and direct edit functionality. But delivering limited Direct Modeling solution that do not have the parametric options. We truly need both.

Is 3D CAD Productivity an Oxymoron?

Conclusion: While Inventor is miles above SW with a much more intuitive UI, it still is limited by the Pro/e Paradigm of separate part, assembly and drawing files.


Not a single model environment
Direct edit functions are steps in the history
Complicated Operations

The above packages are basically Pro/e clones and are virtually
worthless for suppliers that work with many different CAD programs.

#7 CAD Worst Not so bad in the Cloud

Like the Autodesk and PTC subscription only, you are married to Onshape. It is by far the worse solution for any serious engineering firm. You can not save the original file locally, in fact, there is no file format except in the cloud! Your engineering data is out of your control! This product is a very good collaboration tool and has the potential to be the standard in document control.

Onshape! The Party is over!

Onshape - Tech-net signed up to be a representative.

Onshape has been out for a couple of years and I just don't see any value in this program. It offers little more than the above program and locks your data under their control.

Sadly, they did not add any innovation in the modeling functionality, offering no more productivity than a Pro/e Clone. They do have direct edit functionality designed in from the beginning and not some second thought add on feature. It also allows design of parts, assemblies and drawings in the same document. This alone puts miles of the above products. Very few programs can do this, but sadly it "locks" you into the cloud.

Onshape! A View from the Clouds

It costs $1,500.00 per year projects, which is basically maintenance forever. I am not sure this business model will create the revenue. Most will not use Onshape for a modeling package. Onshape does not have a format you can save locally. It is a document that resides only on eh cloud. Personally, I want my engineering stored and available locally especially for archiving. Most will stay with what they are comfortable. I cannot see companies moving to Onshape. The cloud for a company offers no real benefit.


But, outside the scope of this article, Onshape is an incredible collaboration tool. You can upload most popular native parts and assemblies and all of the neutral formats. You can include PDF and other documents and images. You can share you designs with others in any level access, viewing, download and full modifications.

Document Control

Onshape could be a repository of standard documentation deliverables. We would first have to be assured that the cloud is secure. But it solves all of the problems that PLM is now facing. Take a look at an article where I presented this concept. It is easy to set up and the company only needs one paid license. Please read the part on setting up a standard deliverable on a webpage in the above article! Onshape completely serves the purpose.

The Embedded Title Block! A PLM Solution!

OnShape: The Ultimate Document Control System

Cloud Based Engineering Document Control

#8 May be the Ultimate 3D CAD System.

ZW3D - An Incredible Value! - Tech-Net Sells this product

The Ultimate CAD System

Learning Mechanical 3D CAD

ZW3D Advantage over every other system is the Value!
Fully Professional 3D CAD starting at $1,300.00. It truly is worth a look.
Annual Rental Starts at $350.00

I understand that starting with pricing might taint my article. But price is one of the basic reasons for considering this product. It offers, by far, the best price/compatibility ratio.

ZW3D is similar to the above systems. It is incredibly like NX in operation. Its history is a bit different since its history is basically the steps that you have used for the creation of your part. This allows an association with the optional integrated manufacturing Mold/Die Design and CNC Programming.

It has both history and integrated direct editing. It, like IronCAD, can combine all of its history into one easy to modify Brep. It also has Boolean shapes available.

What sets it apart from many systems it that it is the only history based 3D CAD system that can have the part, assembly and drawings in one file. You can design like the Pro/e paradigm and have standalone parts and it has integrated drawings. Very, very nice. Just imagine how, by having the drawing and part/assembly integrated into one file would simplify PLM or PDM?

ZW3D has two levels of design products, a Lite version and a Standard version that adds Free Form Class A Surfacing, Precision Morphing, Sheet Metal and Reverse Engineering. You can add the functionality when needed. It is one of the few truly integrated CAD/CAM solutions plus robust Mold design capabilities. You can design and take it through to manufacturing in one associated product.

What is ZW3D Lite?

ZW3D claim to fame is with its pricing starting at $1,300.00 it is providing CAD as a commodity allowing virtually anyone to afford to have a professional CAD system. You can get 4 seats of ZW3D Lite or 2 ZW3D Standard for the price of one SW or Inventor.

All ZW3D programs include the capability to import Creo (Pro/e), Siemens NX/Solid Edge, Solidworks and Autodesk Inventor native files. Import and export Catia 4/5 native files and all of the standard formats. It includes the PMI information for NX, Creo, Catia and Solidworks.

Free PMI Importer?

Conclusion: If you are a Hobbyist, Designer, Engineer or Inventor thinking about creating your own next great design or to doing consulting work and you don’t have the funds available for the other over priced CAD solutions, look to ZW3D. If you are a company with multiple seat requirements and are tired of paying thousands of dollars for annual maintenance for an overly complex system, look to ZW3D. It offers a very cost effective professional CAD solution and can be easily implemented into your existing engineering process.


Direct edit functions are steps in the history

#9 The Best and Most Productive 3D MCAD System

IronCAD - Tech-Net sells this product

Conceptual Design - Which 3D CAD Paradigm is Best?

Five Functions that Increase CAD Productivity!!

Now for what I consider the best CAD system. IronCAD offers so much more functionality than any of the popular CAD systems. The best functionality above all of the others is the UDE (Unified Design Environment) or what SW Mechanical Conceptual calls the Single Model Environment. This allows you to have many iterations of the same design. Copying and pasting different parts or complete assemblies. They can be copied or linked. You can import large assemblies into SW and it would populate your hard drive with separate parts, assemblies and subassemblies it comes into IronCAD in one easy to handle single design space file with the parts, assemblies and subassemblies defined.

Single Model Environment

It also has robust parametric history based design including both constrained and Innovative part design. Innovative part design allows you do design without defining constraints or concerns about design intent. Also included is integrated direct editing at the touch of the right mouse button. But it handles the direct editing much different than any of the prior products. When a direct edit function affects the basic history, it will consume the history into the solid model thereby giving you a hybrid part with a mixture of history and a Brep. Never to worry, you have all of the robust direct edit functionality to easily continue your design. You even have the ability to turn the model into a single Brep.

The Lost 3D CAD Paradigm or How I Found Freedom in an UNFREE CAD WORLD!

But those are not the only unique features. You design by dragging and dropping standard shapes, positive and negative plus custom shapes, parts and assemblies from an easy accessible standard or custom catalog. Now don’t confuse this with simplistic Boolean shapes, these are complex shapes based on sketches that can be edit. Yes you can have Brep solids also.

Simplifying Your Design Process!

All direct editing packages have a face or feature manipulator that allows you to modify face, shapes or part by moving or copying. But all have basically copied the Triball. This offers the manipulation of virtually all of the features, parts and assemblies miles above the imitators.

While many of the other CAD system have one or two of these features, none have them all. None have the incredibly well designed drag and drop functionality totally unique to IronCAD. Below is a more complete review of the above unique functionality. IronCAD uses both the ACIS and Parasolid Kernel for even more compatibility.

Showing differences in Import - Using Dual Kernel and Repair options.

IronCAD vs Solidworks and the Pro/e Paradigm

All CAD system are basically graphic design packages wrapped in the limitations of Mechanical Design. IronCAD still has many of the graphic design capabilities from the original package allowing it to be used in many more non-engineering related applications. It has integrated realistic rendering and animation plus a great documentation module that makes it a great tool for Tech Pubs, Marketing, Sales and any group that needs to view any data from any CAD system.

Leverage Your Engineering Data throughout your Organization !

Sales, Publication and Marketing!

Checking, Design Review, Manufacturing and Data Extraction

Conclusion: Before you fall victim to one of the Pro/e clones and the dated and complex paradigm. Take a look at the easy to use IronCAD. IronCAD's INOVATE offers a very inexpensive modeling only solution that provides incredible flexibility to your design process, much better than Solidworks Conceptual Design at $1,270.00 as compared to the annual rental fee of $2,988.00.


You have to start somewhere with a new productive standard. IronCAD establishes that standard.

Other Limited Programs

I would not recommend these systems as your only engineering solution because they don't have one or two of the following capabilities: history based design, drafting capabilities or parametric functionality. I believe that history based design is the best for conceptual design. It seems to give more control over the design process in the conceptual design stage. But it can overly complex when design changes are required. An integrated history/direct edit environment is much more productive. Even though I prefer history in my conceptual design I would opt for one of the direct only programs for my tool of choice over the Pro/e clone.

SpaceClaim - Tech-Net sold this product

This was probably the program that pushed the high end systems over the edge, forcing them to consider direct editing.  It is truly the best of the Direct Modeling only packages since it was built from the ground up as direct modeling/editing system. It offered a modeling only package in the beginning, but now is a complete design package. The price is equal to the mid-ranged products that offer more conventional design and direct editing functionality. I believe that direct editing should be an enhancement to history and an integrated part of the design process.

Creo Direct

This is the old CoCreate that was purchased by PTC. It is a dated program. I have used it and found it to be a bit clunky and non-intuitive. My focus with this program was direct editing with non-native parts. I would get strange errors when importing parts into CoCreate, and not sure what it indicated. But it is a fully functional CAD package. I am not sure how smoothly it integrates with Creo Parametrics.

Autodesk Autocad

Sadly Autodesk has gone to Subscription only. This basically moves the product out of contention for a viable design system. No serious company would lock themselves into a subscription only CAD system for very obvious reasons.

You are Not Stuck with Autodesk

I inadvertently left Autocad out of this comparison. I have just a bit of experience with AutoCAD. 30 or so years ago, I got a copy and created a fence for my yard. I was already a 3D Computervision CADDS 4 user and Autocad was tortuous. It was an architecture based package and was not conducive to mechanical design. I was introduced to PC based 3D CADKEY in 1985 while on contract with Boeing. It was designed for 3D mechanical design and I quickly became a dealer. Sad to say CADKEY is gone.

In 2012 I took a job as a Sales/Tech manager for a company that was selling the Autodesk Manufacturing solution. You can read about that experience in the Inventor description above.

All of my sales calls were for Autocad. So against my Autodesk VAR managers wishes I took a bit of time to learn Autocad Mechanical 2012. I found it very similar to my first experience with the 2D interface. But, they now included surfacing and push/pull solid modeling. I found the surfacing easy, fun and adequate for light design. The push/pull solids were also fully functional. I can't remember if you could modify non-native solids. I had some fun playing, but did not do any serious work. I could not get past the idiosyncratic 2D interface. I got an email from a fellow who made me aware I had left Autocad out of this comparison. He is happily doing 3D design in Autocad and seems to be very proud of his 3D work.

I am not sure of all the benefits of Autocad. As I look over the brochures and website I really don't see any reference to the surfacing, solid modeling or the access to Fusion which was included in the package. Can I recommend this package? I really can't, it really is sort of a kludge that I think Autodesk is basically stuck with. But if you are an Autocad user, I would definitely investigate these capabilities before moving to another package. It truly is not your fathers, uh, grandfathers Autocad.

Autodesk Fusion 360

I was going to expand the the latest on Fusion 360, but it is subscription only. This is not a viable option for any serious engineering firm.

You are Not Stuck with Autodesk

Siemens ST

I thought I saw a NX Direct Edit modeling only package. I am sure it would be a great package, ST is a very robust direct editing solution.

Dassault Solidworks Conceptual Design

UPDATE: I was told by a SW VAR that this package does include history capabilities. I have looked over the promotional materials and it has only states direct edit and they do not have evaluation available for download. This is an important feature and should not be overlooked

I am not sure what this package is suppose to add to the Dassault's product line. The introduction video actually points outs the weaknesses of Solidworks and Catia 5. It actually has some nice direct modeling functionality, but who wants a separate package to do your work. I am sure working in Solidworks and incorporating the included direct editing in your design process would be more productive. It has no detailing capabilities and you would have to import it or have access to it inside Solidwork to do the drawings. It offers somewhat bizarre complete collaboration functionality. They seem to think that engineering has dozens of people that have to be involved with the design process. I hate the re-engineering of engineering. There surely enough online collaboration tools.


You might as well buy SpaceClaim or Creo Direct, you would probably be better off and they are fully functional CAD systems. Renting it at $2,988.00 (That must converted from Euros) a year seems to be a poor ROI. Also it has limited translators making it basically a SW add-on. You would think that Dassault would include the capability to directly read/write Catia, thereby adding easy accessible direct edit capabilities to Catia 5, I am sure Boeing and Airbus could would love it.

If you need 3D modeling only, a better solution would be IronCAD INOVATE at the full price of $1,270.00 less than half of the annual subscription of Solidworks Conceptual Design. And you can download it today for a 30 day evaluation. It has an optional translator that reads all of the popular CAD native files plus reads and writes Catia 5. The basic version reads/writes Catia 4 and all of the standard formats (Described below).


If you want to easily create models for 3D printing, rendering or animation, kinematics, etc. INOVATE is the program.

INOVATE is an incredible value. It includes all of IronCAD incredible functionality except for Sheet Metal, Surfacing, Intellishape functionality and Documentation. Just compare it to what SW Mechanical Conceptual offers. It has all of the functionality and more. It has integrated history and direct edit modeling, Integrated realistic rendering and animation, sheet metal unfold, kinematics, Drag and drop design, etc. It is priced at only $1,270.00!

TECH-NET Engineering Services!

We sell and support IronCAD and ZW3D Products and
provide engineering services throughout the USA and Canada!

Why TECH-NET Sells IronCAD and ZW3D

If you would like more information or to download ZW3D or IronCAD

With 52 years of experience in engineering, 17 years in manual board design as a contract engineer, 35 years in 3D CAD sales, support, training and providing engineering services, I have a high level of understanding of today's 3D CAD engineering world. For many it is in chaos. If you are having problems or just interested in this subject please feel free to call and we can discuss them. There are so many simpler solutions available that will save you time and money.

My First 17 Years or "How did we do it without 3D CAD!"

Please visit our Viewpoints
for more interesting articles.

See you online.

Joe Brouwer
Skype: tech-net-inc
